COLORband Pix ILS

COLORband Pix ILS is a feature-packed full-size LED strip light functions as a pixel mapping effect, blinder, or wall washer. Its built-in RF receiver offers wireless control using the RFC or RFC-XL optional remotes and compatibility with ILS which makes creating coordinated light shows across different fixture types easy as 1, 2, 3. But there’s more! COLORband Pix ILS also has D-Fi USB compatibility for wireless Master/Slave or DMX control. Create amazing animations and video effects with individual LED control and access multiple pre-built programs with or without DMX. COLORband Pix ILS is also great for on-camera use because of its flicker-free operation. Easily generate complex shows with ShowXpress Pixels and COLORband Pix ILS is ideal for quiet applications due to its silent operation and no moving parts.

Highlights

  • Full-size LED strip light functions as a pixel mapping effect, blinder, or wall washer

  • Built-in RF receiver for wireless control using the RFC or RFC-XL optional remotes

  • ILS compatibility for use in the ILS ecosystem

  • D-Fi USB compatibility for wireless Master/Slave or DMX control (D-Fi™ USB sold separately)

  • Create amazing animations and video effects with individual LED control

  • Convenient access to multiple pre-built programs with or without DMX

  • Easily generate complex shows with ShowXpress Pixels

  • Achieve flicker-free video operation with high-frequency LED dimming

  • Ideal for quiet applications due to silent operation and no moving parts

  • Easily transports in the optional CHS-60 VIP Gear Bag

Specifications

  • DMX Channels:3, 4, 6, 7, 8, 9, 12, 18, 36 or 41
  • DMX Connectors:3- and 5-pin XLR
  • Light Source:12 LEDs (tri-color RGB) 3 W (1,000 mA), 50,000 hours life expectancy
  • Strobe Rate:0 to 20 Hz
  • Beam Angle:14°
  • Field Angle:27°
  • Illuminance:
    (2m): 4,142 lux @ 2 m
    (5m): 663 lux @ 5 m
  • Lumens:1402
  • Power Linking:19 units @ 120 V; 35 units @ 230 V
  • Power and Current:
    49 W, 0.7 A @ 120 V, 60 Hz
    48 W, 0.4 A @ 230 V, 50 Hz
  • Weight:7 lb (3.2 kg)
  • Size:38.9 x 2 x 6.2 in (987 x 49 x 157 mm)
  • Approvals:CE, MET, UKCA, RoHS
  • Cable Length: 5 ft (1.5 m)
  • Bracket Mounting Hole: 13 mm
  • Optional Controllers: RFC, RFC-XL, DFI-USB

What's Included

  • COLORband Pix ILS
  • Fixture
  • Power cord
  • Quick Reference Guide
