D-Fi XLR RX

DMX control goes from wired to wireless with D-Fi XLR RX! This compact battery-powered wireless D-Fi receiver uses revolutionary CHAUVET DJ technology to provide instant wireless communication by plugging directly into the XLR port of DMX-compatible lights. D-Fi XLR RX receives DMX and master/slave signals between similar fixtures.  Handy LED indicators visually show wireless channel operation. D-Fi XLR RX is fully FCC/RTTE compliant.

Highlights

  • Battery-powered wireless D-Fi receiver provides instant wireless communication

  • Plugs directly into your device’s XLR port

  • Receives DMX and master/slave signals between similar fixtures

  • LED indicators visually show wireless channel operation

  • Works without the need of an external power supply

  • Fully FCC/RTTE compliant

Specifications

  • Max Unobstructed Distance:165 ft (50 m)
  • Maximum Run Time:up to 10 hours
  • Recharge Time:2.5 hours
  • Operating Frequency:2.412 to 2.484 GHz
  • Input Voltage:5 VDC, 500 mA
  • Weight:1.6 oz. (45 g)
  • Size:3.5 x 1 x 1.14 in (88 x 27 x 29 mm)
  • Approvals:CE, FCC, RTTE
  • RF output: 12.72 dBm

What's Included

  • D-Fi XLR RX
  • D-Fi XLR RX
  • Quick reference Guide
