Obey 4
It’s a compact DMX controller for LED wash lights with 3- or 4-channel modes—red, green, blue and white/amber—for easy color-mixing control. It has built-in automated, sound-activated or manual playback options and can control fixtures in four different zones—independently of each other. Its one-touch buttons of pre-mixed colors, built-in chases and strobe and dimmer controls make it perfect for a lighting novice or anyone looking for an easy way to control LED washes.
*includes Mexico & Canada
Highlights
Compact DMX controller designed for LED fixtures with up to 4 channels
– Channel 1: red
– Channel 2: green
– Channel 3: blue
– Channel 4: white (or amber)Easily controls up to 4 separate fixtures
Increase effects by simultaneously operating each fixture in different playback modes with variable fade times
Increase flexibility with playback options that include manual RGBA/RGBW, automated and sound-activated mode
Playback modes:
– Preset: 9 built-in colors
– Chases: manually trigger automated programs
– Color macro: manually scroll through the color spectrum
– RGB fade: automatically scroll through the color spectrum
– RGB fade delay: automatically scroll through the color spectrum with a small delay to each fixture
– Auto: randomly selects different colors for each fixtureIncrease control with adjustable audio sensitivity as well as strobe and blackout effects
Specifications
- DMX Channels:16
- DMX Connectors:3-pin XLR
- Strobe Rate:0 to 33 Hz
- Input Voltage:9 VDC, 500 mA (external power supply: 100 to 240 VAC, 50/60 Hz)
- Weight:3 lb (1.4 kg)
- Size:12.8 x 5.5 x 2.1 in (325 x 140 x 52 mm)
- Approvals:CE
What's Included
- Obey 4
- External power supply
- Quick Reference Guide
- Warranty card
