Xpress-Rack 1024

Xpress-Rack 1024 is a rackmount DMX interface for ShowXpress™ software. The unit controls 2 DMX universes and unlocks an additional ArtNet universe (3 universes total). Easily store and play back 16 shows without a computer using onboard buttons or included remote. Trigger up to 8 scenes remotely using the Phoenix contacts. Xpress-Rack 1024 features a built-in clock and calendar which triggers scenes automatically. Xpress-Rack 1024 is hot-swappable and automatically re-connects within seconds. Compatible with Windows® and Mac OS X systems. Connect multiple interfaces to control additional universes. Both outputs are electrically and optically isolated.

*includes Mexico & Canada

Highlights

  • Rackmount DMX interface for ShowXpress™ software

  • Controls 2 DMX universes and unlocks 1 additional ArtNet universe (3 universes total)

  • Easily store and play back 16 shows without a computer using on onboard buttons or included remote

  • Trigger up to 8 scenes remotely using the Phoenix contacts

  • Built-in clock and calendar triggers scenes automatically

  • Hot-swappable and automatically re-connects within seconds

  • Compatible with Windows® and Mac OS X systems

  • Connect multiple interfaces to control additional universes

  • Both outputs are electrically and optically isolated

Specifications

  • DMX Channels:1024 + 512 via ArtNet
  • DMX Connectors:3-pin XLR
  • Rackmount:1U
  • Input Voltage:5 V USB
  • Weight:2.8 lbs (1.3 kg)
  • Dimensions:19 x 3 x 1.75 in (483 x 76 x 44 mm)
  • Approvals:CE
  • DMX Refresh Rate: 40 Hz

What's Included

  • Xpress-Rack 1024
  • Xpress-Rack 1024
  • USB cable
  • IR extension cable
  • IR remote
